Modular House Light Commercial Prefabricated Buildings Australia Market C89 Light Gauge Steel Framing Machine
description1
Zipper closure
1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in
place during workout
Description
This C89 light gauge steel framing machine is specially optimized to match Australia’s AS/NZS construction standards for prefabricated buildings. It features stable hydraulic punching as the core processing system, fitted with 7 sets of professional punching dies together with one cutting die, bringing a full total of 8 moulds to complete punching, forming and cutting in one streamlined production flow.
Machine List:
|
S.N
|
Equipment name
|
Quantity
|
|
1
|
2 Tons electric decoiler with leveling device
|
1 set
|
|
2
|
Hydraulic punching dies
|
7 sets
|
|
3
|
Oil chiller
|
1 set
|
|
4
|
Main roll forming machine
|
1 set
|
|
5
|
Printer
|
1 set
|
|
6
|
Hydraulic Cutting Device
|
1 unit
|
|
7
|
PLC Control box
|
1 unit
|
|
8
|
Hydraulic station
|
1 unit
|
|
9
|
Out tables
|
2 units
|
|
10
|
Safety cover
|
1 set
|
|
11
|
Spare parts
|
1 Package
|
Machine Specification:
|
1
|
Material Thickness
|
thickness 0.8-1.2mm, G300-G550 Galvanzied coils
|
||
|
2
|
Working Speed
|
About 300-700m/h
|
||
|
3
|
Forming Steps
|
About 9 stations
|
||
|
4
|
Material of Roller
|
Gcr15
|
||
|
5
|
Driven system
|
By chain
|
||
|
6
|
Main motor power
|
7.5 kw
|
||
|
7
|
Cutting type
|
Hydraulic cutting
|
||
|
8
|
Material of cutting
|
Cr12Mov
|
||
|
9
|
Electronic control
|
PLC control
|
||
|
10
|
Hydraulic Station Power
|
7.5 kw
|
||
Application
Wide Application Scenarios
1. Prefabricated Residential Buildings
Mainly for 1–3 storey villas, townhouses, kit homes and tiny houses, the mainstream residential construction type in Australia.
2. Modular & Transportable Units
Produce frames for movable cabins, site accommodation, student dorms and temporary transportable houses.
3. Aged Care & Public Auxiliary Buildings
Suitable for light steel frames of nursing homes, community service rooms and public supporting facilities.
4. Farm & Agricultural Structures
Ideal for farm sheds, livestock houses, agricultural storage warehouses and rural outbuildings.
Ideal for farm sheds, livestock houses, agricultural storage warehouses and rural outbuildings.
5. Light Commercial Premises
Meet frame manufacturing demands for small shops, offices, retail stores and low-rise commercial constructions.
Meet frame manufacturing demands for small shops, offices, retail stores and low-rise commercial constructions.
Solution Advantages
1. Comprehensive After-sales Service
We promptly handle all equipment issues for customers. Remote technical guidance is available, and professional technicians can be dispatched for on-site commissioning to deliver satisfying service.
2. On-time Delivery Guarantee
Reasonable production schedules are formulated to arrange manufacturing orderly. We strictly control progress to ensure goods delivery as scheduled.
3. Complete Spare Parts Supply
Original matching accessories are fully provided, facilitating daily replacement and maintenance to keep machines running steadily.
4. Strict Quality Inspection
All products undergo multi-standard testing before delivery. Every detail is checked rigorously to guarantee reliable overall equipment quality.
We promptly handle all equipment issues for customers. Remote technical guidance is available, and professional technicians can be dispatched for on-site commissioning to deliver satisfying service.
2. On-time Delivery Guarantee
Reasonable production schedules are formulated to arrange manufacturing orderly. We strictly control progress to ensure goods delivery as scheduled.
3. Complete Spare Parts Supply
Original matching accessories are fully provided, facilitating daily replacement and maintenance to keep machines running steadily.
4. Strict Quality Inspection
All products undergo multi-standard testing before delivery. Every detail is checked rigorously to guarantee reliable overall equipment quality.
